Borosilicate Round Gauge Glass
A high safety level is ensured by the use of special borosilicate glass of high chemical durability, exceptional purity and homogeneity. Combined with thermal pre-stressing (tempering), high precision processing Auer Lighting guarantees sight and level gauge glasses of highest quality.Our special tempered reflex and transparent level gauge glasses and disc sight glasses can be supplied in a wide variety of sizes to fulfill our customers’ requests.
| Borosilicate Round Gauge Glass | Strength Ø x mm | Allowable Operating Pressure in Bar | Strength Ø x mm | Allowable Operating Pressure in Bar |
|---|
| Borosilicate Round Gauge Glass | 95 x 15 | 16 | 150 x 10 | 2 |
| Borosilicate Round Gauge Glass | 100 x 10 | 7 | 150 x 15 | 8 |
| Borosilicate Round Gauge Glass | 100 x 12 | 10 | 150 x 20 | 10 |
| Borosilicate Round Gauge Glass | 100 x 15 | 16 | 150 x 25 | 16 |
| Borosilicate Round Gauge Glass | 100 x 25 | 40 | 175 x 20 | 10 |
| Borosilicate Round Gauge Glass | 100 x 20 | 25 | 150 x 30 | 25 |
| Borosilicate Round Gauge Glass | 113 x 15 | 10 | 175 x 25 | 16 |
| Borosilicate Round Gauge Glass | 125 x 15 | 10 | 200 x 25 | 10 |
| Borosilicate Round Gauge Glass | 125 x 20 | 16 | 200 x 30 | 16 |
| Borosilicate Round Gauge Glass | 125 x 25 | 25 | 250 x 20 | 4 |
| Borosilicate Round Gauge Glass | 125 x 30 | 40 | 250 x 25 | 8 |
| Borosilicate Round Gauge Glass | 130 x 15 | 10 | 250 x 30 | 10 |
| Borosilicate Round Gauge Glass | 135 x 25 | 25 | 265 x 30 | 8 |
| Borosilicate Round Gauge Glass | 120 x 15 | 10 | 200 x 20 | 8 |
| Borosilicate Round Gauge Glass | 115 x 15 | 10 | 175 x 30 | 25 |
| | | | |
Plexiglass PDF Technical Table
Borosilicate round gauge glass PDF
Borosilicate round gauge glass Safety precautions when using sight glass discs: Whenever a sight glass assembly has been taken apart it is urgently recommended in accordance with DIN 7080/ DIN 8902 that the glass disc and gaskets are replaced by new ones. That is particularly important in the case of pressure vessels and/or aggressive media. The following extract from DIN 7080/DIN 8902 text is verbatim:
